CAD1501 Assignment 2 Pass Guaranteed Correctly

Answered Questions

________ enables you to split a part into tow bodies along the split reference. - CORRECT

ANSWER ✔✔ -Split Solid

________ enables you to split faces. The entire part remains as one object, but the faces can be

manipulated separately. - CORRECT ANSWER ✔✔ -Split face

________ enables you to trim a part. A portion of the part is removed using the toggle direction

icons. - CORRECT ANSWER ✔✔ -Trim Solid

A work axis can be used as a reference when creating a work plane. - CORRECT ANSWER ✔✔

-True

After editing the dimensions of a part model, you must open all drawings referencing that part to

make the same dimension changes? - CORRECT ANSWER ✔✔ -False

All constraints must be manually assigned to the sketched geometry. - CORRECT ANSWER

✔✔ -False

An Origin Plane cannot be selected as a sketch plane. - CORRECT ANSWER ✔✔ -False

Any features below the end of part marker in the Model browser are still displayed, but you

cannot select them as references when creating new features. - CORRECT ANSWER ✔✔ -False

, Based on the constraint symbols shown in Figure 3-74, which constraint types are applied to the

bottom horizontal entity? (Select all that apply.) - CORRECT ANSWER ✔✔ -1. parallel

2. tangent

Chamfer features always remove material. - CORRECT ANSWER ✔✔ -False

Clicking (look at) enables you to automatically reorient the display of the model to its top view: -

CORRECT ANSWER ✔✔ -False

Construction entities can be used directly to create solid geometry? - CORRECT ANSWER ✔✔

-True/False?

Fillet features can add or remove material. - CORRECT ANSWER ✔✔ -True

Fillets and chamfers that are added in the sketch become separate Fillet and Chamfer features in

the Model browser one the sketch has been completed. They can be selected and deleted

independent of sketch. - CORRECT ANSWER ✔✔ -False

Fillets on multiple edges can be controlled by one dimension. - CORRECT ANSWER ✔✔ -True

How can a section view be saved to the model? - CORRECT ANSWER ✔✔ -A section view is

saved with the model in a Design View and can be retrieved in the Model Browser

How can you modify an existing place feature, such as a fillet or chamfer? - CORRECT

ANSWER ✔✔ -Double-click on the feature in the model or in the Model browser.
